Optimize with advanced pump control

At RLAY, we use an advanced and flexible pump control solution built on Siemens technology. The pump control controller is based on an open PLC system, allowing for multiple connections in one unit. This enables us to ensure maximum efficiency and user-friendliness.

An advanced and flexible solution that includes:

Quick and easy setup

The advanced pump control solution is designed to be user-friendly and efficient. With a guided setup process, any operator can set up a pump station in just half an hour, after which it is ready for operation. The pump control controller is built on Siemens' latest PLC controller, Simatic 1512SP, which is a compact system with high performance and easy expansion capabilities. The open system architecture allows a PLC programmer with Siemens software to service and expand the system as needed.

Full integration

The controller is Ethernet-based, providing full access to all parameters and ensuring complete control from SCADA systems. This means that there are no limitations on communication methods, making full integration also a possibility.

User-friendly operating system

The operating system is built with the latest SCADA pump control standard from the supplier. The system can be installed on a Windows platform, as a tablet or standard PC, and is designed to provide a clear overview of the pump station's status. The system is configurable for up to four pumps with many customization options that are continuously developed to meet customer needs.

Advanced features

• Heating and cooling control: Integrated PT 100 sensors in the controller allow for ventilation and heating control in the panel, and temperature development can be monitored via the SCADA system.
• Energy optimization: With built-in energy optimization features and frequency-controlled pumps, significant savings can be achieved.
• Step control: The system offers step control, which allows for individual control of each pump on four operating steps, making the system highly flexible.
• Automatic wear control: Built-in wear control continuously monitors the pump's condition and automatically alerts in case of deviations, assuming the pump station is equipped with a flow meter on the discharge pipe.

Integration with Siemens Ethernet-based frequency converters

For optimal integration, the controller is compatible with Siemens Ethernet-based frequency converters, which allows for parameter changes from the SCADA system and an extended alarm list. The controller can also be adapted to other Ethernet-based frequency converters or for communication with digital and analog controls according to the customer's preferences.
